ALL Stainless Steel SS316 Accumulators, Specially Designed for Food Industry, Energy Services or Highly Corrosive Applications.

Bladder accumulators with stainless steel SS316 material are available at Reasontek Corporation from 1 gallon to 15 gallons (contact us for other special sizes).
Shell materials are ASME certified per ASME Boiler & Pressure Vessel Code, Section VIII, Division 1 with U stamp.
Various bladder materials available for different fluid media and temperature requirement. Standard NPT fluid port, ASME flange connections are optional and made by order.

Specifications:

SHELL MATERIAL

Stainless Steel, SS316

SERVICE TEMPERATURE

STANDARD (Buna-N)

-20° F to 200° F (-40° C to 94° C)

RATED PRESSURE

2,000 psi (138 Bar)

Tested in accordance with ASME Boiler & Pressure Vessel Code Section VIII, Division 1, ASME Certified, U Stamped

SPECIAL CONFIGURATIONS

Noted by “X” at end of Model Number, defined by Part Number and Assembly Drawing



Please check our new accumulator site for more details



If you need help for sizing or selecting the accumulator for your project, please download and fill out the Accumulator Application Form and send to us.
